How to load balance traffic using interface groups?

Load balancing weights can be defined as shown above for each interface contained in the Interface Group Interfaces. These weights indicate the proportion of traffic desired for the given interface.

In this example, the weights are set to 0.7 for WAN1 and 0.3 for WAN2, which results in 70% of the traffic being directed to WAN1 and 30% of the traffic being directed to WAN2.

NOTE: For all traffic to obey the interface group weights, you would need to enable “HTTP aggregation exclusion” as well. Or else you HTTP/HTTPS will still be load-balanced as per the configured “HTTP aggregation weights” (if HTTP weights are not configured then the default is 1:1)
